M-SYSTEM Indicators Digital Panel Meters

http://www.m-system.com

Last Update

Price:

R.F.Q.

A field indicator is used for local indication for operators' convenience while signals from sensors and transmitters installed throughout a large installation of tanks and pipelines are typically transmitted to a control/monitoring station via 4-20 mA current line. The loop powered indicator is simple to install and wire, and reliable and durable in an explosive corrosive environment.

Share Product:

Detail

Bright, Colorful LED 47L Series

  • 1/8 DIN size (96 x 48 mm)
  • Red, Orange, Green, Bluegreen, Blue and white LED selectable
  • 4 or 4 1/2 digit display
  • Alarm and/or transmitter output optional
  • IP66 front panel
  • Separable terminal block

Large 0.8" High LED display 40 Series

  • 1/8 DIN size (96 x 48 mm)
  • 3 1/2 or 4 digit display
  • Display hold function
  • 4-digit process meter with scaling (40DV, 40DN, 40DPT, 40DCT)
  • 24 Vdc powered
  • 100-120 Vac, 200-240 Vac powered (40DV, 40 DR, 40DT, 40DPT, 40DCT)
  • No external power source needed (40DN)
  • Hold function

High Performance LCD Display 47D Series

  • 1/8 DIN size (96 x 48 mm)
  • 5 1/2 digit display plus small 20 segment bargraph
  • Main display color can be changed from green to red in alarm
  • Alarm and/or transmitter output optional 12 V or 24 Vdc sensor excitation
  • RS-485 Modbus-RTU interface optional
  • IP66 front panel
  • Separable terminal block

1/32 DIN Size Meters 43 Series

  • 1/32 DIN size (48 x 24 mm)
  • Easy-to-wire tension clamp connecting
  • 24 Vdc powered or loop powered (no external power supply required)

Specification

Keyword
System Indicators Digital
Brand
OriginJP
